Electrical Characteristics |
| Range of nominal resistance :
........................................................................... 10W~2MW |
| Resistance tolerance :
.................................................................................................. ¡Ó10% |
| Terminal resistance :
..................................................................................... £1%R
or
2W |
| Contact resistance variation :
........................................................................... £3%R or 3W |
|
|
Environment Characteristics |
|
Rated Power : ..................................................... (200V
max ) +70¢XC 0.25W ,+125¢XC
0W |
|
Temperature range
:
................................................................................... -55¢XC ~+ 125¢XC
|
| TCR
:
..................................................................................................... ¡Ó100, ¡Ó250ppm/¢XC |
|
Temperature variation
: ........................................... -55¢XC, 39min, +125¢XC, 39min 5 cycles |
|
...................................................... DR£¡Ó1%R, D(Uab/Uac)
£¡Ó1% |
|
Vibration :
................................................................... 10~500Hz,
0.75mm, or 98m/s2, 6h |
|
..............................................................................DR£2%R, D
(Uab/Uac) £3% |
|
|
Physical
Characteristics |
|
Total Mechanical Travel :
.................................................................................
22
¡Ó 5 turns |
|
Starting Torque :
................................................................................................
£30mN.m |
|
Standard Packing :
......................................................................................
25 Pcs per tube |
|
Stoping Torque :
................................................................................................
£36mN.m |
|
Withstand Voltage :
.................................................... 101.3KPa 600Vac, 8.5KPa
350Vac |
| Insulation resistance :
.......................................................................... Ri ³1GW ( 100Vac) |
|
Effective electrical travel : ............................................... > 70% of total mechanical travel |
| Collision :
..................................................................... 390m/s2, 4000 cycles;
DR£¡Ó2%R |
|
Climate category : .........................................................................
DR£¡Ó3%R,R1³100MW |
| Electrical
endurance : .............................................................. 0.75W, 1000h;
DR£10%R |
|
Mechanical Endurance ; .............................................. 200cycles
DR£10%R, CRV£5%R |
|
Steady damp-heat :
..................................................................
DR£¡Ó3%R,
R1³100MW |
|
| DOWNLOAD
3006 SPECIFICATION |
|
 |
