Electrical Characteristics |
Standard Resistance Range : ......................................................................... 10 Wto 2 MW |
Resistance tolerance : ................................................................................................. ± 10% |
Terminal Resistance : .................................................................................... £ 1%R or 2W |
Contact resistance variation : ............................................................................. £3% or 3W |
Environment Characteristics |
Rated Power : ..................................................... (315V max ) ±70°C 0.5W ±125°C 0W |
Temperature Range : .................................................................................. -55°C to +125°C |
TCR : .................................................................................................... ±100 , ±250ppm/°C |
Temperature Variation : .................................... -55°C , 30mins, +125°C , 30mins 5 cycles |
......................................................DR£±3%R, D(Uab/Uac) £±1% |
Climate Category : ..................................................................... DR£±3%R , R¹ ³100MW |
Physical Characteristics |
Starting torque : ..................................................................................................£20mN. m |
Standard Packaging : .................................................................................. 50pcs . Per tube |
Withstand voltage : ..................................................... 101.3KPa 500Vac ; 8.5KPa 315Vac |
Insulation resistance : ........................................................................ R¹ ³ 1G W (100Vac) |
Effective electrical travel : .................................................. ³70% of total mechanical travel |
Vibration : .................................................................. 10~200Hz, 0.75mm or 98m/s² , 6h |
.......................................................................... DR£±3%R, D(Uab/Uac) £±2% |
Collision : .................................................................... 390m/s² , 40000 cycles DR£±3%R |
Electrical endurance at 70°C : ...................... 0.5W, 1000h DR£±10%R, CRV£±3% or 3W |
Rotational Life : ............................................ 200 (cycles) DR£±10%R, CRV£±3% or 3W |
Steady damp-heat : ....................................................................... DR£±3%R, R¹³100MW |
Total mechanical travel : ..................................................................................... ³250° ±10° |
Stoping torque : .................................................................................................. ³35mN.m |
