Electrical Characteristics |
Standard Resistance Range : ............................................................................ 10 W~2MW |
Absolute Minimum Resistance : .................................................................... £1%R or 2W |
Insulation Resistance : ......................................................................... R¹³1GW (100Vac) |
Effective electrical travel : ................................................... ³70% of total mechanical travel |
Environment Characteristics |
Power Rating (200V max ) : ................................................... +70°C 0.5W + 125°C 0W |
Temperature Coefficient : ...................................................................... ±100, ±250ppm/°C |
Rotational Life : ........................................................................... (200 cycles) DR£±10%R |
Collision : ....................................................................... 390m/s², 4000 cycles DR£±5%R |
Electrical Endurance at 70°C : .................................................. 0.5W, 1000h DR£±10%R |
Climate Category : ........................................................................ DR£±3%R, Rı³100MW |
Physical Characteristics |
Total Mechanical Travel : ................................................................................... 280° ± 10° |
Starting Torque : ................................................................................................. £20mN.m |
Resistance Tolerance : ................................................................................................ ±10% |
Contact Resistance Variation : ........................................................................... £3% or 3W |
Withstand Voltage : .................................................... 101.3KPa 500Vac ; 8.5KPa 350Vac |
Temperature Range : ................................................................................... -55°C ~ +125°C |
Temperature Variation : ....................................... -55°C, 30Min, +125°C 30Min (3 Cycles) |
..................................................... DR£±2%R , D(Uab/Uac)£±5% |
Steady Damp-heat : ..................................................................... DR£±3%R, Rı ³100MW |
Vibration : ...................................................................10~500Hz, 0.75mm or 98m/s² , 6h |
.......................................................................... DR£±1%R , D(Uab/Uac)£±2% |
Standard Packaging : .................................................................................... 50Pcs per tube |
Stoping Torque : ................................................................................................. ³50mN.m |
