Electrical Characteristics |
|
Range of nominal resistance : 100 W~100K W |
|
Resistance tolerance : ¡Ó5% ¡Ó 10% |
|
Terminal resistance : £1%R or 10W |
|
Contact resistance variation : CRV£3% or 3W |
|
Withstand Voltage : 500Vac ( 100Kpa ) |
|
Insulation resistance : Ri ³
200M W |
|
Limit current of moving contact : 100mA |
|
Effective electrical travel : 3600 ¡Ó > 70%
of total mechanical travel |
|
|
Environment Characteristics |
| Rated Power (315V max )
2W @ 40¢XC 0W @ 105¢XC |
|
Temperature variation -55¢XC, 30min, +125¢XC, 30min |
|
DR£1%R |
|
Vibration : 20~600Hz, 50M/S, 10min |
|
electrical interruption¡Ø100£gs
DR£1%R |
|
Collision : 390m/s2,
4000 cycles;
DR£5%R |
|
Climate category meet IEC68-2-2 etc.; DR£10%R,R1³100MW |
|
Electrical endurance at 70¢XC 40¡Ó2¢J, 2W, 48h; DR£1%R |
|
Mechanical Wear-resistance : 2500cycles DR£2%R |
|
Steady damp-heat |
|
40¡Ó2¢J, 93%R.H. 48h; DR£1%R,
R1³20MW |
|
| Physical
Characteristics
|
|
Total Mechanical Travel 3600 |
|
Starting Torque £20mN.m |
|
Mark |
|
Resistance tolerance (when no identification, |
|
It is of ¡Ó10%) resistance code type |
|
|
|
|
|
|
|
 |
